Straight single-wall extruded aluminum blade. Great versatility. With the same profile we have three different doors of feelings and utilities. Elegant aesthetics.
– Surface Total coverage closed 100 mm
– Weight approx. m² 10 kg
– Max. width approx. 7,000 mm
– Max. height approx. 7,000 mm
– Minimum rolling diameter 133 mm
– Blind profile | Microperforado | Die-cut 240/510×70
– Class III wind
– RC3 Burglary
Roll-up door in extruded aluminum of high strength 6063-T5 alloy (Aluminum, Silicon, Magnesium and Titanium) from the brand PORTALUM Model XT-20. Made with straight design profiles and with single-wall geometry with its main measurements of 100×15.4 mm and its general thickness of 2 mm. The roll-up door is complemented by side nylon plugs that prevent movement between the slats and possible operating noises, a double-walled reinforced lower plinth with rubber weatherstripping for watertightness, as well as for the best fit to the sill and aluminium side guides with anti-friction polyamide weatherstripping that prevents friction and wear of the slats. The XT-20 model offers great versatility of finishes and versions of the blind, perforated with and without methacrylate, mixed and micro-perforated plank that will be able to meet all aesthetic requirements.
