XT-80 Industrial Roll-Up Door

Straight extruded aluminum slat with double wall, which allows installations facing inwards or outwards without losing either aesthetics or performance.

PROTECT

XT-80

Characteristics

– Surface Closed total coverage 80 mm
– Weight approx. m² 12.5 kg
– Max. width approx. 5,500 mm
– Max. height approx. 4,500 mm
– Minimum rolling diameter 133 mm
– Blind profile
– XT-79 ->Microperforated terminals | Die-cut 100/220×38

Roll-up door in extruded aluminum of high strength 6063-T5 alloy (Aluminum, Silicon, Magnesium and Titanium) from the brand PORTALUM Model XT-80. Made with straight design profiles and double-wall geometry, its main measurements being 80×15.4 mm and its general thickness of 1.4 mm. The roll-up door is complemented by side nylon plugs that prevent movement between the slats and possible operating noises, a reinforced double-walled lower plinth with rubber weatherstripping for better watertightness and greater adjustment to the sill. In addition to the aluminium side guides, with anti-friction polyamide weatherstripping, to prevent friction and wear of the slats. The XT-80 model offers great versatility of finishes and the combination of the XT-79 perforated plank with and without methacrylate, mixed and microperforated that will be able to meet all aesthetic requirements.
